Windows 10: How Xbox Series X|S Integrates Full AMD RDNA 2 Architecture

Brink · Oct 30, 2020

We here at Team Xbox would like to congratulate and celebrate our amazing partners at AMD on todayâs announcement of the Radeon RX 6000 Series of RDNA 2 GPUs. It was incredible to see AMD demonstrate the power and potential that the new AMD RDNA 2 architecture can deliver to gamers around the globe. AMD continues to be an industry leader in CPU and GPU innovation, bringing next-generation capabilities to the PC, console and cloud.

The long-term strategic relationship between Xbox and AMD over the past 15 years, beginning with the Xbox 360, is at the heart of the Xbox Series X and Xbox Series S. With the upcoming launch of the Xbox Series X|S on November 10, together we are ushering in the next generation of gaming delivering a level of power, performance and compatibility never before seen in console gaming, powered by AMDâs latest âZen 2â and RDNA 2 architectures. Xbox Series X|S are the only next-generation consoles with full hardware support for all the RDNA 2 capabilities AMD showcased today.

AMDâs latest RDNA 2 architecture delivers a significant increase in performance and efficiency over previous architectures, as well as adding new hardware acceleration capabilities including hardware accelerated DirectX Raytracing, Mesh Shaders, Sampler Feedback and Variable Rate Shading. Hardware accelerated DirectX Raytracing, showcased at launch by titles such as Ubisoftâs Watch Dogs: Legion, enables developers to deliver a new level of visual fidelity and immersion through techniques such as realistic lighting, shadows, reflections and acoustics. Mesh Shaders can manipulate geometry in real time to provide a high level of fidelity and flexibility that developers have never had before. Sampler Feedback greatly improves memory efficiency by allowing games to load into memory, with fine granularity, only the portions of textures that the GPU needs for a scene, as it needs it, providing an effective 2.5x memory and bandwidth multiplier beyond the raw hardware capabilities. Sampler Feedback also enables efficient creation and shading of textures on-demand.

Finally, Variable Rate Shading (VRS) delivers much finer grain control on how developers can leverage the full power of the Xbox Series X|S by enabling developers to focus their GPU resources on the areas of a frame that most benefit without reducing the overall image quality. By leveraging techniques like VRS, games such as Gears 5 can see performance increases up to 15% and beyond resulting in higher, more consistent frame rates and resolution at the exact same image quality. All of these next-generation capabilities are available via hardware in both the Xbox Series X and Series S and we are excited for them to also come to PC, providing a common set of features that developers can rely on when developing their games across console and PC.

At the very beginning of development of the Xbox Series X | S, we knew we were setting the foundation for the next decade of gaming innovation and performance across console, PC and cloud. To deliver on this vision we wanted to leverage the full capabilities of RDNA 2 in hardware from day one. Through close collaboration and partnership between Xbox and AMD, not only have we delivered on this promise, we have gone even further introducing additional next-generation innovation such as hardware accelerated Machine Learning capabilities for better NPC intelligence, more lifelike animation, and improved visual quality via techniques such as ML powered super resolution.

In our quest to put gamers and developers first we chose to wait for the most advanced technology from our partners at AMD before finalizing our architecture. Now, with the upcoming release of Xbox Series X|S and the new AMD Radeon RX 6000 Series GPUs, developers have a common set of next-generation tools and performance capabilities that will empower them to deliver transformative gaming experiences across both console and PC.

We are extremely proud of the results gamers will see at launch from titles such as Gears 5, Assassinâs Creed Valhalla, Dirt 5, and many, many more, but we are even more excited by how developers will be able to take further advantage of these next-generation innovations in the future, resulting in a level of visual fidelity and immersion never before thought possible in console gaming.

We want to thank AMD for their continued partnership, and we congratulate them on the announcements today as they usher in the next generation of graphics technology into the PC ecosystem. With less than two weeks from the global launch of Xbox Series X and Xbox Series S on November 10, we canât wait to kick off the next decade of gaming with you.
Click to expand...

Source: A Closer Look at How Xbox Series X|S Integrates Full AMD RDNA 2 Architecture - Xbox Wire

Tweet

— Twitter API (@user) View on Twitter
Click to expand...

:)

Brink · Oct 30, 2020

Xbox Velocity Architecture on Xbox Series X

When we set out to design the Xbox Series X, we aspired to build our most powerful console ever powered by next generation innovation and delivering consistent, sustained performance never before seen in a console with no compromises. To achieve this goal, we knew we needed to analyze each component of the system, to push beyond the limitations in traditional console performance and design. It was critical in the design of the Xbox Series X to ensure we had a superior balance of power, speed and performance while ensuring no component would constrain the creative ambition of the world’s best creators, empowering them to deliver truly transformative next gen gaming experiences not possible in prior console generations.

At the heart of the Xbox Series X is our custom processor leveraging the latest RDNA 2 and Zen 2 architectures from our partners at AMD to deliver a best in class next generation processor delivering more than 12 TFLOPs of GPU power and more than 4 times the CPU processing power of the Xbox One X. Xbox Series X includes the highest memory bandwidth of any next generation console with 16GB of GDDR6 memory, including 10GB of GPU optimized memory at 560 GB/s to keep the processor fed with no bottlenecks. As we analyzed the storage subsystem, it became clear that we had reached the upper limits of traditional hard drive technology and to deliver on our design aspirations, we would need to radically rethink and revolutionize our approach with the Xbox Series X.

Empowering Next Generation Game Design and Creative Vision

Modern games require a significant amount of data to create the realistic worlds and universes that gamers experience. To enable the processor to work at its optimum performance, all of this data must be loaded from storage into memory. The explosion of massive, dynamic open-world environments and living, persistent worlds with increased density and variety has only increased the amount of data required. From environmental mesh data, high polygon character models, high resolution textures, animation data, audio and video source files and more all combine together to deliver the most immersive game play environment for the player.

Despite the ability for modern game engines and middleware to stream game assets into memory off of local storage, level designers are still often required to create narrow pathways, hallways, or elevators to work around the limitations of a traditional hard drive and I/O pipeline. These in-game elements are often used to mask the need to unload the prior zone’s assets from memory while loading in new assets for the next play space. As we discussed developers’ aspirations for their next generation titles and the limitations of current generation technology, this challenge would continue to increase exponentially and further constrain the ambition for truly transformative games. This feedback influenced the design and development of the Xbox Velocity Architecture.

Introducing the Xbox Velocity Architecture

The Xbox Velocity Architecture was designed as the ultimate solution for game asset streaming in the next generation. This radical reinvention of the traditional I/O subsystem directly influenced all aspects of the Xbox Series X design. If our custom designed processor is at the heart of the Xbox Series X, the Xbox Velocity Architecture is the soul. Through a deep integration of hardware and software innovation, the Xbox Velocity Architecture will power next-gen gaming experiences unlike anything you have seen before.

The Xbox Velocity Architecture comprises four major components: our custom NVME SSD, hardware accelerated decompression blocks, a brand new DirectStorage API layer and Sampler Feedback Streaming (SFS).
Let’s dive deep into each component:

Custom NVME SSD: The foundation of the Xbox Velocity Architecture is our custom, 1TB NVME SSD, delivering 2.4 GB/s of raw I/O throughput, more than 40x the throughput of Xbox One. Traditional SSDs used in PCs often reduce performance as thermals increase or while performing drive maintenance. The custom NVME SSD in Xbox Series X is designed for consistent, sustained performance as opposed to peak performance. Developers have a guaranteed level of I/O performance at all times and they can reliably design and optimize their games removing the barriers and constraints they have to work around today. This same level of consistent, sustained performance also applies to the Seagate Expandable Storage Card ensuring you have the exact same gameplay experience regardless of where the game resides.

Hardware Accelerated Decompression: Game packages and assets are compressed to minimize download times and the amount of storage required for each individual game. With hardware accelerated support for both the industry standard LZ decompressor as well as a brand new, proprietary algorithm specifically designed for texture data named BCPack, Xbox Series X provides the best of both worlds for developers to achieve massive savings with no loss in quality or performance. As texture data comprises a significant portion of the total overall size of a game, having a purpose built algorithm optimized for texture data in addition to the general purpose LZ decompressor, both can be used in parallel to reduce the overall size of a game package. Assuming a 2:1 compression ratio, Xbox Series X delivers an effective 4.8 GB/s in I/O performance to the title, approximately 100x the I/O performance in current generation consoles. To deliver similar levels of decompression performance in software would require more than 4 Zen 2 CPU cores.

New DirectStorage API: Standard File I/O APIs were developed more than 30 years ago and are virtually unchanged while storage technology has made significant advancements since then. As we analyzed game data access patterns as well as the latest hardware advancements with SSD technology, we knew we needed to advance the state of the art to put more control in the hands of developers. We added a brand new DirectStorage API to the DirectX family, providing developers with fine grain control of their I/O operations empowering them to establish multiple I/O queues, prioritization and minimizing I/O latency. These direct, low level access APIs ensure developers will be able to take full advantage of the raw I/O performance afforded by the hardware, resulting in virtually eliminating load times or fast travel systems that are just that . . . fast.

Sampler Feedback Streaming (SFS): Sampler Feedback Streaming is a brand-new innovation built on top of all the other advancements of the Xbox Velocity Architecture. Game textures are optimized at differing levels of detail and resolution, called mipmaps, and can be used during rendering based on how close or far away an object is from the player. As an object moves closer to the player, the resolution of the texture must increase to provide the crisp detail and visuals that gamers expect. However, these larger mipmaps require a significant amount of memory compared to the lower resolution mips that can be used if the object is further away in the scene. Today, developers must load an entire mip level in memory even in cases where they may only sample a very small portion of the overall texture. Through specialized hardware added to the Xbox One X, we were able to analyze texture memory usage by the GPU and we discovered that the GPU often accesses less than 1/3 of the texture data required to be loaded in memory. A single scene often includes thousands of different textures resulting in a significant loss in effective memory and I/O bandwidth utilization due to inefficient usage. With this insight, we were able to create and add new capabilities to the Xbox Series X GPU which enables it to only load the sub portions of a mip level into memory, on demand, just in time for when the GPU requires the data. This innovation results in approximately 2.5x the effective I/O throughput and memory usage above and beyond the raw hardware capabilities on average. SFS provides an effective multiplier on available system memory and I/O bandwidth, resulting in significantly more memory and I/O throughput available to make your game richer and more immersive.

Through the massive increase in I/O throughput, hardware accelerated decompression, DirectStorage, and the significant increases in efficiency provided by Sampler Feedback Streaming, the Xbox Velocity Architecture enables the Xbox Series X to deliver effective performance well beyond the raw hardware specs, providing direct, instant, low level access to more than 100GB of game data stored on the SSD just in time for when the game requires it. These innovations will unlock new gameplay experiences and a level of depth and immersion unlike anything you have previously experienced in gaming.

Unlocking Next Generation Experiences

What does this all mean for you as a gamer? As the industry’s most creative developers and middleware companies have begun to explore these new capabilities, we expect significant innovation throughout the next generation as this revolutionary new architecture enables entirely new scenarios never before considered possible in gaming. The Xbox Velocity Architecture provides a new level of performance and capabilities well beyond the raw specifications of the hardware itself. The Xbox Velocity Architecture fundamentally rethinks how a developer can take advantage of the hardware provided by the Xbox Series X. From entirely new rendering techniques to the virtual elimination of loading times, to larger, more dynamic living worlds where, as a gamer, you can choose how you want to explore, we can’t be more excited by the early results we are already seeing. In addition, the Xbox Velocity Architecture has opened even more opportunities and enabled new innovations at the platform level, such as Quick Resume which enables you to instantly resume where you left off across multiple games, improving the overall gaming experience for all gamers on Xbox Series X.

We can’t wait for gamers around the world to get to experience these new, next generation gaming experiences on Xbox Series X this holiday and beyond. For more information on the Xbox Velocity Architecture, check out the video above.
Click to expand...

Source: Xbox Velocity Architecture: A Closer Look at the Next-Gen Tech Driving Gaming Innovation Forward on Xbox Series X - Xbox Wire

Tweet

— Twitter API (@user) View on Twitter
Click to expand...

Brink · Oct 30, 2020

AMD announces Radeon RX 5700 series GPU with GDDR6 powered by RDNA

AMD High-Performance Gaming Updates

AMD unveiled RDNA, the next foundational gaming architecture that was designed to drive the future of PC gaming, console, and cloud for years to come. With a new compute unit10 design, RDNA is expected to deliver incredible performance, power and memory efficiency in a smaller package compared to the previous generation Graphics Core Next (GCN) architecture. It is projected to provide up to 1.25X higher performance-per-clock11 and up to 1.5X higher performance-per-watt over GCN12, enabling better gaming performance at lower power and reduced latency.

RDNA will power the upcoming 7nm AMD Radeon RX 5700-series graphics cards which feature high-speed GDDR6 memory and support for the PCIe 4.0 interface.

During the keynote, Dr. Su showcased the power of RDNA and one of the new AMD Radeon RX 5700-series graphics cards in a head-to-head comparison with a RTX 2070 card running a Strange Brigade gameplay demo, beating the competition delivering incredible ~100 FPS gaming.

AMD Radeon RX 5700-series graphics cards are expected to be available in July 2019. Learn more at the AMD E3 livestream event on June 10, 2019 at 3 pm PT.

jy0Q75xCwDU
Click to expand...

Read more:

https://www.amd.com/en/press-release...x-2019-keynote

https://www.amd.com/en/events/computex

Tweet

— Twitter API (@user) View on Twiiter[/quote]

Tweet

— Twitter API (@user) View on Twiiter
Click to expand...

Tenforo · Oct 30, 2020

AMD announces Radeon RX 5700 series GPU with GDDR6 powered by RDNA

AMD High-Performance Gaming Updates

AMD unveiled RDNA, the next foundational gaming architecture that was designed to drive the future of PC gaming, console, and cloud for years to come. With a new compute unit10 design, RDNA is expected to deliver incredible performance, power and memory efficiency in a smaller package compared to the previous generation Graphics Core Next (GCN) architecture. It is projected to provide up to 1.25X higher performance-per-clock11 and up to 1.5X higher performance-per-watt over GCN12, enabling better gaming performance at lower power and reduced latency.

RDNA will power the upcoming 7nm AMD Radeon RX 5700-series graphics cards which feature high-speed GDDR6 memory and support for the PCIe 4.0 interface.

During the keynote, Dr. Su showcased the power of RDNA and one of the new AMD Radeon RX 5700-series graphics cards in a head-to-head comparison with a RTX 2070 card running a Strange Brigade gameplay demo, beating the competition delivering incredible ~100 FPS gaming.

AMD Radeon RX 5700-series graphics cards are expected to be available in July 2019. Learn more at the AMD E3 livestream event on June 10, 2019 at 3 pm PT.

Click to expand...

Read more:

https://www.amd.com/en/press-release...x-2019-keynote

https://www.amd.com/en/events/computex

Tweet

— Twitter API (@user) View on Twitter
Click to expand...

Tweet

— Twitter API (@user) View on Twitter
Click to expand...
