Windows 10: Install windows-10 on gpt SSD under legacy BIOS

Discus and support Install windows-10 on gpt SSD under legacy BIOS in Windows 10 Installation and Upgrade to solve the problem; #1I want to install w10 on a gpt ssd in a legacy bios box to multi-boot with several Linux distros, is this possible? I think I've done it before a... Discussion in 'Windows 10 Installation and Upgrade' started by frauentrauti, Apr 23, 2025.

  1. Install windows-10 on gpt SSD under legacy BIOS


    #1I want to install w10 on a gpt ssd in a legacy bios box to multi-boot with several Linux distros, is this possible? I think I've done it before a long time ago but forget the details.#2This machine is being prepped for disposal, is it legal to pre-install and let the ultimate owner register it or whatever that protocol is called these days?TIA

    :)

    frauentrauti, Apr 23, 2025
    #1
  2. DaveM121 Win User

    Installing Windows 10 on SSD, program asks for MBR and GPT

    Hi Turbo Sean

    On all modern PC's that SSD must have a partition Style of GPT, is is only older systems with Legacy BIOS that will have a hard drive formatted to MBR . . .

    1

    Disconnect that other drive, leaving just the installation media and the SSD Connected

    2

    To convert your Drive to GPT:

    At the very start of the Installation Process, press Shift + F10, or Shift + Fn + F10 to open Command Prompt

    Run this command and hit Enter:

    diskpart

    Run this command and hit Enter:

    list disk

    (Make note of the disk number you want to convert and enter it into the next command - replace disknumber)

    Run this command and hit Enter:

    select disk disknumber

    Run this command and hit Enter:

    clean

    Run this command and hit Enter:

    convert gpt

    Then close Command Prompt

    Begin the installation . . .

    DaveM121, Apr 23, 2025
    #2
  3. NavyLCDR Win User
    drive needs to be formatted as GPT but BIOS is legacy and not UEFI

    Are you sure your BIOS is legacy? Windows setup will only require a GPT partitioned drive if the Windows installation media is booted into in UEFI mode. What did you use to create your Windows 10 installation media with... I'll bet RUFUS?

    NavyLCDR, Apr 23, 2025
    #3
  4. Brink Win User

    Install windows-10 on gpt SSD under legacy BIOS

    Convert Windows 10 from Legacy BIOS to UEFI without Data Loss


    Here it is:


    Brink, Apr 23, 2025
    #4
