Windows 10: IntelR Wi-Fi 6E AX120 160Mhz - Unable to create 5GHz Hotspot

Dhruv1414 · Jul 20, 2022

Hi,PC is on opposite end of the house from router, and is plugged into Ethernet.Recently bought a TP-Link AX3000 with the intention of using it for Hotspot-WIFI with Meta Quest 2 in the same room as my PC.Windows 10 Hotspot unable to create with 5GHz, only with 2.4Ghz does it work. Otherwise message 'The selected network band isn't available'.I have read to change settings under device manager:802.11acPreferred Band 5GhzDisable 6GHz I have read drivers may confuse 5/6GHz and 6GHz is not supported with WindowsDriver Version: 22.150.0.3It seems this is a known issue after researching, but ther

:)

nasher02 · Jul 20, 2022

5ghz Hotspot not working

I have tried to set 6Ghz as the preferred band but it doesn't affect anything.

Although I mainly use the ethernet, I can connect to the router via Wi-Fi at 5ghz:

-------------------------------------------------------------------------------------

Protocol: 802.11a

Security type: WPA2-Personal

Network band: 5 GHz

Network channel: 108

Link speed (Receive/Transmit): 36/54 (Mbps)

Manufacturer: Intel Corporation

Description: Intel(R) Wi-Fi 6E AX210 160MHz

Driver version: 22.110.1.1

---------------------------------------------------------------------------------------

The Virgin Hub 4 uses the older Wi-Fi 5 standard (802.11ac), there's a new WiFi 6 model out but I haven't been e-mailed about the upgrade yet.

Setting the preferred band to no preference and the network band to any available, enables the hotspot but only at 2.4ghz

Disabling Bluetooth doesn't resolve the issue

Brink · Jul 20, 2022

Wi-Fi 6E extends Wi-Fi CERTIFIED 6 into 6 GHz

Capacity, efficiency, and performance for advanced connectivity

Wi-Fi CERTIFIED 6™, the industry certification program based on the IEEE 802.11ax standard, enables next generation Wi-Fi connectivity providing the capacity, coverage, and performance required by users—even in environments with many connected devices such as stadiums and other public venues. Wi-Fi CERTIFIED 6 networks enable lower battery consumption in devices, making it a solid choice for any environment, including smart home and Internet of Things (IoT) uses.

Key benefits of Wi-Fi CERTIFIED 6 technology include:

Higher data rates

Increased capacity

Performance in environments with many connected devices

Improved power efficiency

Wi-Fi CERTIFIED 6 provides the foundation for a host of existing and emerging uses from streaming ultra high-definition movies, to mission-critical business applications requiring high bandwidth and low latency, to staying connected and productive while traversing large, congested networks in airports and train stations.

Wi-Fi 6E extends Wi-Fi CERTIFIED 6 into 6 GHz

Wi-Fi operation in the 6 GHz frequency band enables Wi-Fi to continue delivering positive experiences for the most bandwidth-intensive applications. Wi-Fi 6E certification as part of Wi-Fi CERTIFIED 6 offers the features and capabilities of Wi-Fi 6, extended to the 6 GHz band. Several nations around the globe are making the 6 GHz band available for unlicensed use, and Wi-Fi CERTIFIED 6 provides worldwide interoperability certification for devices in these markets.

COUNTRIES ENABLING WI-FI 6E

Wi-Fi 6E can utilize up to 14 additional 80 MHz channels or seven additional superwide 160 MHz channels in 6 GHz for applications such as high-definition video streaming and virtual reality. Wi-Fi 6E devices leverage these wider channels and additional capacity to deliver greater network performance and support more Wi-Fi users at once, even in very dense and congested environments. Wi-Fi 6E will bring greater technology advancements in Wi-Fi that will introduce new use cases, such as unified communications, cloud computing, and telepresence, and accelerate the next generation connectivity with 5G networks.

Innovation and performance in challenging environments

The ubiquity of Wi-Fi and its ability to complement other wireless technologies helps bring the promise of connecting everyone and everything, everywhere, closer to reality. Wi-Fi popularity has also created very diverse and densely populated Wi-Fi conditions, requiring technological advances to meet the needs of users. Wi-Fi CERTIFIED 6 delivers improvements and new features that enable Wi-Fi devices to operate efficiently in the most dense and dynamic connectivity settings.

Key capabilities:

Orthogonal frequency division multiple access (OFDMA) effectively shares channels to increase network efficiency and lower latency for both uplink and downlink traffic in high demand environments

Multi-user multiple input, multiple output (multi-user MIMO) allows more downlink data to be transferred at one time, enabling access points (APs) to concurrently handle more devices

160 MHz channel utilization capability increases bandwidth to deliver greater performance with low latency

Target wake time (TWT) significantly improves network efficiency and device battery life, including IoT devices

1024 quadrature amplitude modulation mode (1024-QAM) increases throughput for emerging, bandwidth intensive uses by encoding more data in the same amount of spectrum

Transmit beamforming enables higher data rates at a given range to increase network capacity

Wi-Fi CERTIFIED 6 devices bring enhanced performance to emerging applications such as virtual and augmented reality used in e-Learning, telepresence, and healthcare. Wi-Fi CERTIFIED 6 also provides carriers and public Wi-Fi operators with more capabilities to support advanced connectivity in retail, stadiums, and transportation hubs, including a growing array of location-based applications and services.

Click to expand...

Source: Wi-Fi CERTIFIED 6 | Wi-Fi Alliance

See also: Wi-Fi Alliance® brings Wi-Fi 6 into 6 GHz as Wi-Fi 6E

Er.Luz · Jul 20, 2022

Microsoft Wi-Fi Direct Virtual Adapter Limitations ????

My pc has an intel Ax210 wifi card (https://www.intel.com/content/www/u...6/intel-wifi-6e-ax210-gig/specifications.html).

I spent a few weeks trying to create a Wifi hotspot on 5Ghz or use wifi direct on 5Ghz. However, all connections through the Microsoft Wi-Fi Direct Virtual Adapter are limited to 2.4 GHz at 144 Mbps. When I select 5ghz in Wifi hotspot, the error that selected band is not available appears. I believe this limitation is due to Microsoft Wi-Fi Direct Virtual Adapter (2.4 Ghz -144 Mbps).

Is there any way to change Microsoft Wi-Fi Direct Virtual Adapter settings?

Best regards,

Er.
