Windows 10: New Qualcomm ultraSAW RF Filter Technology for 5G/4G Mobile Devices

Brink · Feb 19, 2020

Qualcomm Technologies, Inc. today announced the QualcommÂ® ultraSAW filter technology, another groundbreaking innovation in the companyâs industry-leading wireless technology portfolio that builds on the companyâs legacy of developing breakthrough technologies and enabling new experiences and expanding the mobile ecosystem.

Radio frequency (RF) filters isolate radio signals from the different spectrum bands that phones use to receive and transmit information. By achieving as much as 1 decibel (dB) improvement in insertion loss, Qualcomm ultraSAW filters offer a higher performance solution compared to competing bulk-acoustic (BAW) filters in the sub-2.7 GHz frequency range.

High performance filter technology enhances RF Front-End portfolio including modules and discrete filters

Qualcomm ultraSAW technology achieves superior filter characteristics to deliver high performance in frequencies from 600 MHz to 2.7 GHz with a range of benefits:

Excellent transmit, receive and cross isolation

High frequency selectivity

A Q-factor of up to 5000 â significantly higher than the quality factor of competing BAW filters

Very low insertion loss

Excellent temperature stability with very low temperature drift in the single-digit ppm/Kelvin range.

This allows for more power-efficient RF paths in 5G and 4G multimode mobile devices â and at a lower cost point than competing commercial solutions with similar performance metrics for original equipment manufacturers (OEMs).

Source: calibrated measurements in Qualcomm Technologiesâ labs comparing Qualcomm ultraSAW pre-commercial components with commercially available products

âOur thin-film innovation offers game-changing performance improvements compared to existing BAW technologies,â says Christian Block, senior vice president and general manager, RFFE, QUALCOMM Germany RFFE GmbH. âAs the worldâs leading wireless technology innovator, Qualcomm continuously pushes the boundaries of whatâs possible in mobile technology. With growing filter content in 5G designs, our OEM customers are excited about the attractive combination of higher filter performance and lower cost that Qualcomm ultraSAW enables.â

Qualcomm ultraSAW serves as a key technology for driving the performance of Qualcomm Technologiesâ cutting-edge RFFE product portfolio and QualcommÂ® Snapdragonâ¢ 5G Modem-RF Systems further. We are integrating Qualcomm ultraSAW technology across our product line including PA modules (PAMiD), front-end modules (FEMiD), diversity modules (DRx), Wi-Fi extractors, GNSS extractors and RF multiplexers.

Improved RF performance helps OEMs bring 5G devices with superior connectivity and battery life to consumers. With a lineup of discrete and integrated Qualcomm ultraSAW products beginning production this quarter, OEM flagship devices using the technology are expected to be commercially available in the second half of 2020.
Click to expand...

Source: Qualcomm Announces Breakthrough Qualcomm ultraSAW RF Filter Technology for 5G/4G Mobile Devices | Qualcomm

:)

Brink · Feb 19, 2020

Qualcomm accelerates 5G across Snapdragon 8, 7, and 6 series in 2020 Mobile

At IFA 2019, Qualcomm Technologies, Inc., a subsidiary of Qualcomm Incorporated, announced their plans to accelerate 5G global commercialization at scale by expanding its portfolio of 5G mobile platforms across the Snapdragon 8 Series, 7 Series and 6 Series in 2020. With over 150 5G designs launched or in development to date using the Company’s 5G solutions, Qualcomm Technologies is driving the proliferation of 5G across multiple tiers to make the next-generation of camera, video, AI and gaming experiences more broadly available. This expanded portfolio rollout aims to support features and frequency bands globally and has the potential to make 5G accessible to more than 2 billion smartphone users.

“Qualcomm Technologies delivered the world’s first and most advanced 5G mobile platform including the first comprehensive Modem-RF System to accelerate 5G commercialization in 2019,” said Alex Katouzian, senior vice president and general manager, mobile, Qualcomm Technologies, Inc. “And we are uniquely positioned to accelerate 5G commercialization to scale globally with our OEM and operator customers with expanded mobile platform offerings across our Snapdragon 8 Series, 7 Series and 6 Series in 2020.”

These new mobile platforms will be the first in a roadmap of software-compatible 5G mobile platforms and take advantage of the Snapdragon 5G Modem-RF System. This breakthrough Snapdragon system is designed to deliver best-in-class cellular performance, coverage, power-efficiency, and cutting-edge form factors in 5G devices, at global scale. Snapdragon’s expanded portfolio of 5G mobile platforms is designed to support all key regions and frequency bands including mmWave and sub-6 GHz spectrum, TDD and FDD modes, 5G multi-SIM, Dynamic Spectrum Sharing, and Standalone (SA) and non-standalone (NSA) network architectures – providing flexibility and enabling 5G network deployment roadmaps globally.

The flagship Snapdragon 8 Series is already powering leading 5G mobile devices that were introduced globally in 2019. More details on the next generation Snapdragon 8 Series 5G Mobile Platform will come later this year.

First to announce an integrated 5G platform back in February of this year, the Company’s Snapdragon 7 Series 5G Mobile Platform will have 5G integrated into a SoC (System-on-Chip) and support all key regions and frequency bands. This highly efficient mobile platform built on 7nm process technology is designed to exceed what is expected from today’s high-tier mobile experiences by bringing select premium-tier features, including the next gen Qualcomm® AI Engine and select Qualcomm® Snapdragon Elite Gaming™ features, to a broader audience.

Twelve leading global OEMs and brands including OPPO, realme, Redmi, Vivo, Motorola, HMD Global, the home of Nokia smartphones, and LG Electronics, plan to use this new integrated Snapdragon 7 Series 5G mobile platform in their future 5G mobile devices. The integrated Snapdragon 7 Series 5G Mobile Platform began sampling to customers in the second quarter of 2019. With exceptional progress, Qualcomm Technologies has accelerated the commercial readiness of this platform to fourth quarter of 2019 with devices expected to launch soon thereafter. Full details of the platform will be disclosed later this year.

The Snapdragon 6 Series 5G Mobile Platform is designed to make 5G user experiences even more broadly available in alignment with operators’ deployment plans to deliver 5G coverage around the world. The Snapdragon 6 Series is known for bringing the most asked for mobile experiences to the masses. Devices based on the Snapdragon 6 Series 5G Mobile Platform are expected to be commercially available in the second half of 2020 proliferating 5G globally.
Click to expand...

Source: Qualcomm Accelerates 5G Commercialization at Scale with Multiple Tiers of Snapdragon 5G Platforms Launching in 2020 | Qualcomm

Brink · Feb 19, 2020

Samsung announces mass production of Exynos 5G and RF chips

Samsung Electronics, a world leader in advanced semiconductor technology, today announced that its 5G communication solutions are in mass production for the latest premium mobile devices. The 5G multi-mode chipsets include the previously-introduced Exynos Modem 5100 as well as a new single-chip radio frequency transceiver, the Exynos RF 5500, and supply modulator solution, the Exynos SM 5800, all supporting 5G New Radio (5G-NR) sub-6-gigahertz (GHz) spectrum and legacy radio access technologies that provide mobile device manufacturers with optimum network communication solutions for the 5G era.

“Samsung has been an innovator in mobile communication technologies with a strong portfolio of market-proven solutions, and we are well-prepared to extend our leadership into 5G,” said Inyup Kang, president of System LSI Business at Samsung Electronics. “Our multi-mode solutions, the Exynos Modem 5100, Exynos RF 5500 and Exynos SM 5800 will together enable powerful yet energy-efficient 5G performance along with the network versatility that allows users to stay connected wherever they are.”

Exynos Modem 5100 is Samsung’s first 5G modem solution that had completed preparations for commercialization in August, 2018, with a successful over-the-air (OTA) 5G-NR data call test. The modem supports virtually all networks from 5G’s sub-6GHz and mmWave spectrums to 2G GSM/CDMA, 3G WCDMA, TD-SCDMA, HSPA and 4G LTE networks in a single chip.

For reliable and power-efficient performance, the modem is paired with RF and supply modulator solutions, Exynos RF 5500 and Exynos SM 5800 respectively.

Samsung’s Exynos RF 5500 supports legacy networks and 5G-NR sub-6GHz networks in a single chip, offering added flexibility in smartphone designs, especially for today’s premium mobile devices. RF transceivers are key components that allow smartphones to transmit and receive data over the cellular network. When transmitting voice or data from a smartphone to a carrier, the RF up-converts the modem’s baseband signal to high GHz-range cellular frequencies so that data can be sent swiftly over the connected network. Vice versa, when receiving, the signal is down-converted by the RF to baseband frequencies for it to be processed by the modem. The Exynos RF 5500 has 14 receiver paths for download, and supports 4×4 MIMO (Multiple-Input, Multiple-Output) and higher-order 256 QAM (Quadrature Amplitude Modulation) scheme to maximize the data transfer rate over the 5G network.

The Exynos SM 5800 is a low-power supply modulator solution for 2G to 5G-NR sub-6GHz that supports up to 100MHz envelope-tracking (ET) bandwidths. As the possibilities for richer content with higher data rates open up with the arrival of 5G, maintaining a highly efficient RF has become more critical in ensuring a longer battery life in a mobile device. The Exynos SM 5800 demonstrates up to a 30-percent power reduction by dynamically adjusting the supply voltage according to the modem’s RF input signal. With an advanced power optimizing ET solution for RF, data can be transmitted more efficiently and reliably over the incredibly fast 5G network.

Both the Exynos RF 5500 and SM 5800’s technological breakthroughs have been recognized by the International Solid-State Circuits Conference (ISSCC) committee and were presented at ISSCC 2019 held at San Francisco last February.

As the industry moves forward to unfold and discover the full benefits of 5G, Samsung plans to continue pushing for innovation in mobile communication technologies, including RF transceiver and phased array solutions for mmWave along with 5G-embedded mobile processors, that will further drive the proliferation of new applications in mobile devices and emerging industries.
Click to expand...

Source: https://news.samsung.com/global/sams...bile-consumers

Brink · Feb 19, 2020

Qualcomm Announces Snapdragon 855 Plus Mobile Platform Mobile

Qualcomm Technologies, Inc., a subsidiary of Qualcomm Incorporated (NASDAQ: QCOM), unveiled the Qualcomm® Snapdragon™ 855 Plus Mobile Platform, a follow on to the flagship Snapdragon 855 launching with leading OEMs globally, built for speed to support enhanced performance and deliver leading experiences in multi-gigabit 5G, gaming, AI and XR. The platform features a boost in performance that will raise gaming to the next level for a truly Qualcomm® Snapdragon™ Elite Gaming experience—especially when gaming in the 5G arena. “Snapdragon 855 Plus will raise the bar for elite gamers with the increase in CPU and GPU performance and elevate experiences for 5G, gaming, AI and XR, which is something our OEM customers look to us to deliver,” said Kedar Kondap, vice president, product management, Qualcomm Technologies, Inc.

“Snapdragon 855 Plus is our most advanced mobile platform to date and will build upon the success of the 2019 Android flagship Snapdragon 855 5G mobile platform.”

Snapdragon 855 Plus with an integrated multi-gigabit Snapdragon X24 LTE 4G modem also supports 5G connectivity using the X50 5G modem and Qualcomm Technologies’ RF Front-end solutions to deliver best-in-class cellular performance, superior coverage and all-day battery life in premium 5G devices. The platform also offers the following enhancements over Snapdragon
855:

Qualcomm® Kryo™ 485 CPU Prime core clock speed at up to 2.96GHz

Qualcomm® Adreno™ 640 GPU offers a 15% increase

Snapdragon 855 Plus includes many of the latest technologies and features from Qualcomm Technologies related to gaming, AI and XR, offering consumers outstanding performance for premium user experiences for the things they want to do most:

Gaming: Snapdragon 855 Plus is built for speed to support enhanced performance and deliver leading experiences in gaming. The Snapdragon Elite Gaming Experience gives you a competitive edge with a full suite of hardware and software features that are fully optimized for gaming, including the Vulkan 1.1 Graphics Driver that is 20% more power efficient than Open GL ES. The Snapdragon Elite Gaming Experience also features software enhancements such as Game Jank Reducer, Game Fast Loader, Game AntiCheat Extensions, and more.

AI: Experience ultra-responsive gaming with the 4th generation multi-core Qualcomm®

AI Engine, which offers a total capacity of more than 7 trillion operations per second (7 TOPs), providing a powerful blend of dedicated and programmable AI acceleration

XR: Experience immersive XR (virtual reality/augmented reality) easily with XR viewers that connect to a mobile device fueled by the Snapdragon 855 Plus with the 5G X50 modem, able to access blazing-fast, ultra-smooth 5G experiences.

Commercial devices based on Snapdragon 855 Plus are expected to be commercial 2H 2019. For full specifications on Snapdragon 855 Plus visit: Snapdragon 855+ Mobile Platform | Snapdragon 855 Plus | Qualcomm.
Click to expand...

Source: Qualcomm Announces Snapdragon 855 Plus Mobile Platform | Qualcomm
