Windows 10: reagentc confusion...

Can someone explain this behavior?C:\Windows\System32>reagentc /enable REAGENTC.EXE: Operation Successful. C:\Windows\System32>reagentc /info Windows Recovery Environment Windows RE and system reset configuration Information: Windows RE status: Disabled Windows RE location: Boot Configuration Data BCD identifier: 00000000-0000-0000-0000-000000000000 Recovery image location: Recovery image index: 0 Custom image location: Custom image index: 0 REAGENTC.EXE: Operation Successful.

:)



ReAgentC will not enable

Oh derp!

Copying the Recovery folder from a known-good-working computer and pasting it to the not-working computer does not work. C:\Windows\System32\Recovery\ReAgent_Merged.xml1 file is custom created on-the-fly for each machine.

1. Check to see if Windows\System32\Recovery\ folder exists;
   • if N skip to next step;
   • if Y rename it RecoveryBUP or something similar, then continue;
2. using 7-Zip or similar navigate the installation media to ...\Sources\ install.wim or install.esd
3. double-click either and go to ...\1\Windows\System32\
4. click the Recovery folder and tell 7-Zip to extract it to the target machine at C:\Windows\System32\;
5. reboot
6. Go to Settings > Update & Security > click Recovery in the left menu list;
7. under Advanced startup click Restart now
8. You should now see the full Recovery console like this:

MBR2GPT.EXE is a Microsoft program included free in Windows. If running Windows 10 v 1803 or later and the objective is to convert MBR to GPT with NO data loss, MBR2GPT.exe will do that. It is fast and works well. MS posted a video of it in use at their site. There is also an updated step-by-step tutorial at WindowsCentral with pictures. The steps follow:

In order to enable UEFI on a UEFI-able system that has been using BIOS because it was running Windows 7 or some such, the MBR (master boot record) first must be converted to GPT (GUID partition table):

• click Command Prompt in the Recovery Console to open an elevated command prompt without the Windows GUI;
• that should bring you to C:\Windows\System32;
• type MBR2GPT.exe /validate;
• type MBR2GPT.exe /convert and await the successful conversion;
  • there may be an error message about reagentc.exe, you can ignore that until after you change the CMOS/BIOS settings

now change BIOS to UEFI:

• reboot and tap F12 continuously before the Windows logo appears (or whatever key your device requires to enter the BIOS settings)
• change boot to UEFI from BIOS & reboot
• DONE

Now, ensure the Recovery console is as you want it...

1. In Windows launch an elevated command prompt and navigate to C:\Windows\System32
2. type reagentc /info and tap [enter], if disabled
3. type reagentc /enable and tap [enter]

RESOLVED & DONE with much thanks to SIW2 and NavyLCDR!



LITTLE CONFUSIONS ABOUT REAGENTC COMMANDS

Hi RAJU.MSC,

REAgentC.exe is a tool that you can use to configure a Windows Recovery Environment (Windows RE) boot image and a push-button reset recovery image, and to administer recovery options and customizations.

For an in-depth assistance regarding your REAgentC command-line concern, we suggest that you post your query on the
TechNet
forum. This forum is a community that is mainly composed of IT professionals who can cater to the complexity of your concern. I am positive that you will be getting all the information that you need from our experts. Good luck.

To notify us and have us get back to you, simply reply to this post.



ReagentC "operation failed: 32"

Hello.

What, exactly, does "operation failed: 32" mean when it comes from ReagentC?

Is their a published list of all of the ReagentC failure numbers, and what they mean or what triggers them?
