Windows 10: SSD Partition not showing in Disk Management/File Explorer

So I was running Windows 11 for a long time, then suddenly I started getting a blue screen error. So I ran a clean installation of Windows 10. After this, the blue screen error stopped but I couldn't upgrade to Windows 11, it gives an error message but unfortunately I didn't take note of the error code. Now I decided to run another clean installation but this time I formatted the system reserved partitions too. When I proceeded to install, I get the error message: "Windows cannot install required files. Make sure all files required for installation are available, and restart the installa

:)



Partition appeared in File Explorer, does not show up in Disk Management

Hi Ja_Mo

Since that is formatted as FAT32, do you have a 129GB SD Card inserted into your PC?

If not, did you mount any ISO file recently, if you right click that new drive (partition) do you get the 'Eject' option?

Whatever that drive (partition) is, it is not part of either your SSD or 1TB HDD, because those are showing correctly in both File Explorer and Disk Management . . .



Disk management console view is not up-to-date

i dont know how to fix your disk management, but i can fix your partition problems...




open up Command Prompt with admin rights. (Right click, run as admin)


enter in
DISKPART
list disk

then find the Disk number for your Raid array... lets call it number 7 ( you can tell what disk is what by the total size)
type in

Select Disk 7
List Partition (will give you a list of all the partitions..)
Select Partition 1 (im assuming you only have 1 partition on Disk 7) repeat this step if you have more partitions.
ASSIGN


that should get the array up and running ready to use.


EDITED.

any problems, post back ^^


Still EDITING *Stick Out Tongue

side question, have you tried restarting the PC?



Help! Data partition not showing under my computer

This is happening on a windows 2000 server. Our second partition of the system, for data is not showing under my computer. Here are the properties of it in disk management:





Now under logical drives its listed as F and shows free space available.

Suggestions on how to fix this?
