Windows 10: Wi-Fi 6E support for Windows 10 Intel AX210 Wireless card

Saurabh_Mist · Apr 11, 2021

Hi Team,

I have installed a Intel Wi-Fi 6E AX210 160MHz card on my Windows PC and have installed latest drivers. I have also subscribed to Windows insider program and I am running 19043.906 Build.

The problem is the Wi-Fi explorer is not seeing the 6GHz SSID. However, I have a Samsung S21 Ultra phone which connects to 6G router without any issues.

Is there anything else I need to configure/Enable ? We are planning to buy bunch of AX210 cards for our internal testing.

Please respond at the earliest.

Regards,

Saurabh

:)

Brink · Apr 11, 2021

Wi-Fi 6E extends Wi-Fi CERTIFIED 6 into 6 GHz

Capacity, efficiency, and performance for advanced connectivity

Wi-Fi CERTIFIED 6™, the industry certification program based on the IEEE 802.11ax standard, enables next generation Wi-Fi connectivity providing the capacity, coverage, and performance required by users—even in environments with many connected devices such as stadiums and other public venues. Wi-Fi CERTIFIED 6 networks enable lower battery consumption in devices, making it a solid choice for any environment, including smart home and Internet of Things (IoT) uses.

Key benefits of Wi-Fi CERTIFIED 6 technology include:

Higher data rates

Increased capacity

Performance in environments with many connected devices

Improved power efficiency

Wi-Fi CERTIFIED 6 provides the foundation for a host of existing and emerging uses from streaming ultra high-definition movies, to mission-critical business applications requiring high bandwidth and low latency, to staying connected and productive while traversing large, congested networks in airports and train stations.

Wi-Fi 6E extends Wi-Fi CERTIFIED 6 into 6 GHz

Wi-Fi operation in the 6 GHz frequency band enables Wi-Fi to continue delivering positive experiences for the most bandwidth-intensive applications. Wi-Fi 6E certification as part of Wi-Fi CERTIFIED 6 offers the features and capabilities of Wi-Fi 6, extended to the 6 GHz band. Several nations around the globe are making the 6 GHz band available for unlicensed use, and Wi-Fi CERTIFIED 6 provides worldwide interoperability certification for devices in these markets.

COUNTRIES ENABLING WI-FI 6E

Wi-Fi 6E can utilize up to 14 additional 80 MHz channels or seven additional superwide 160 MHz channels in 6 GHz for applications such as high-definition video streaming and virtual reality. Wi-Fi 6E devices leverage these wider channels and additional capacity to deliver greater network performance and support more Wi-Fi users at once, even in very dense and congested environments. Wi-Fi 6E will bring greater technology advancements in Wi-Fi that will introduce new use cases, such as unified communications, cloud computing, and telepresence, and accelerate the next generation connectivity with 5G networks.

Innovation and performance in challenging environments

The ubiquity of Wi-Fi and its ability to complement other wireless technologies helps bring the promise of connecting everyone and everything, everywhere, closer to reality. Wi-Fi popularity has also created very diverse and densely populated Wi-Fi conditions, requiring technological advances to meet the needs of users. Wi-Fi CERTIFIED 6 delivers improvements and new features that enable Wi-Fi devices to operate efficiently in the most dense and dynamic connectivity settings.

Key capabilities:

Orthogonal frequency division multiple access (OFDMA) effectively shares channels to increase network efficiency and lower latency for both uplink and downlink traffic in high demand environments

Multi-user multiple input, multiple output (multi-user MIMO) allows more downlink data to be transferred at one time, enabling access points (APs) to concurrently handle more devices

160 MHz channel utilization capability increases bandwidth to deliver greater performance with low latency

Target wake time (TWT) significantly improves network efficiency and device battery life, including IoT devices

1024 quadrature amplitude modulation mode (1024-QAM) increases throughput for emerging, bandwidth intensive uses by encoding more data in the same amount of spectrum

Transmit beamforming enables higher data rates at a given range to increase network capacity

Wi-Fi CERTIFIED 6 devices bring enhanced performance to emerging applications such as virtual and augmented reality used in e-Learning, telepresence, and healthcare. Wi-Fi CERTIFIED 6 also provides carriers and public Wi-Fi operators with more capabilities to support advanced connectivity in retail, stadiums, and transportation hubs, including a growing array of location-based applications and services.

Click to expand...

Source: Wi-Fi CERTIFIED 6 | Wi-Fi Alliance

See also: Wi-Fi Alliance® brings Wi-Fi 6 into 6 GHz as Wi-Fi 6E

Brink · Apr 11, 2021

Latest Windows 10 Wi-Fi Drivers for Intel Wireless Adapters

Latest Windows 10 Wi-Fi Drivers for Intel Wireless Adapters

Downloads page for Intel Wireless Networking

Note WHQL version: 21.90.3
Release Date: May 20, 2020

Download: Windows 10 Wi-Fi Drivers for Intel Wireless Adapters

Release Notes

This download is valid for the product(s) listed below.

Intel® Dual Band Wireless-AC 3165

Intel® Dual Band Wireless-AC 3168

Intel® Dual Band Wireless-AC 7265

Intel® Dual Band Wireless-AC 8260

Intel® Dual Band Wireless-AC 8265

Intel® Dual Band Wireless-AC 8265 Desktop Kit

Intel® Dual Band Wireless-N 7265

Intel® Wi-Fi 6 (Gig+) Desktop Kit

Intel® Wi-Fi 6 AX200

Intel® Wi-Fi 6 AX201

Intel® Wireless-AC 9260

Intel® Wireless-AC 9461

Intel® Wireless-AC 9462

Intel® Wireless-AC 9560

Intel® Wireless-N 7265

JamesAndersonJr · Apr 11, 2021

Is Windows 10 Pro 20H2 FULLY Compatible with Wi-Fi 6E Yet?

Is Windows 10 Pro 20H2 FULLY compatible with Wi-Fi 6E, yet? If not, will 21H1 be compatible?

Note: Wi-Fi 6E is different from Wi-Fi 6.

Thanks in Advance.
