Windows 10: Windows 10 2004 RDS/RDP issue

Hi,

after the forced Windows 2004 Update, its not possible to use the RDS to the local machine reliable anymore. When i reboot the machine I am able to use RDP on it for one session only. If i disconnect of sign out and try to reconnect I get the error that the RDS might not be available anymore.

Other serives like chrome remote desktop are still working properly. Is there a solution to fix the RDS?
Thanks,

Event viewer logs the following faults:
Error:
A fatal hardware error has occurred. A record describing the condition is contained in the data section of this event.
- <Event xmlns="http://schemas.microsoft.com/win/2004/08/events/event">
- <System>
<Provider Name="Microsoft-Windows-WHEA-Logger" Guid="{c26c4f3c-3f66-4e99-8f8a-39405cfed220}" />
<EventID>1</EventID>
<Version>0</Version>
<Level>2</Level>
<Task>0</Task>
<Opcode>0</Opcode>
<Keywords>0x8000000000000002</Keywords>
<TimeCreated SystemTime="2020-07-28T12:43:37.752367800Z" />
<EventRecordID>3797</EventRecordID>
<Correlation ActivityID="{683f749c-8686-475c-bc98-8e862949cdd6}" />
<Execution ProcessID="4324" ThreadID="5876" />
<Channel>System</Channel>
<Computer>DESKTOP-QDSF452</Computer>
<Security UserID="S-1-5-19" />
</System>
- <EventData>
<Data Name="Length">462</Data>
<Data Name="RawData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ata>
</EventData>
</Event>

Critical:
The device Microsoft Remote Display Adapter location unknown is offline due to a user-mode driver crash. Windows will attempt to restart the device 5 more times. Please contact the device manufacturer for more information about this problem.
- <Event xmlns="http://schemas.microsoft.com/win/2004/08/events/event">
- <System>
<Provider Name="Microsoft-Windows-DriverFrameworks-UserMode" Guid="{2e35aaeb-857f-4beb-a418-2e6c0e54d988}" />
<EventID>10111</EventID>
<Version>1</Version>
<Level>1</Level>
<Task>64</Task>
<Opcode>0</Opcode>
<Keywords>0x2000000000000000</Keywords>
<TimeCreated SystemTime="2020-07-28T13:05:09.033419900Z" />
<EventRecordID>4665</EventRecordID>
<Correlation />
<Execution ProcessID="940" ThreadID="668" />
<Channel>System</Channel>
<Computer>DESKTOP-QDSF452</Computer>
<Security UserID="S-1-5-18" />
</System>
- <UserData>
- <UmdfDeviceOffline xmlns="http://www.microsoft.com/DriverFrameworks/UserMode/Event">
<LifetimeId>{423c624a-94af-4419-a83a-102a25fc7b3d}</LifetimeId>
<FriendlyName>Microsoft Remote Display Adapter</FriendlyName>
<Location>unknown</Location>
<InstanceId>SWD\REMOTEDISPLAYENUM\RDPIDD_INDIRECTDISPLAY&SESSIONID_0003</InstanceId>
<RestartCount>5</RestartCount>
</UmdfDeviceOffline>
</UserData>
</Event>

A problem has occurred with one or more user-mode drivers and the hosting process has been terminated. This may temporarily interrupt your ability to access the devices.
- <Event xmlns="http://schemas.microsoft.com/win/2004/08/events/event">
- <System>
<Provider Name="Microsoft-Windows-DriverFrameworks-UserMode" Guid="{2e35aaeb-857f-4beb-a418-2e6c0e54d988}" />
<EventID>10110</EventID>
<Version>1</Version>
<Level>1</Level>
<Task>64</Task>
<Opcode>0</Opcode>
<Keywords>0x2000000000000000</Keywords>
<TimeCreated SystemTime="2020-07-28T13:05:09.031523000Z" />
<EventRecordID>4664</EventRecordID>
<Correlation />
<Execution ProcessID="940" ThreadID="668" />
<Channel>System</Channel>
<Computer>DESKTOP-QDSF452</Computer>
<Security UserID="S-1-5-18" />
</System>
- <UserData>
- <UMDFHostProblem xmlns="http://www.microsoft.com/DriverFrameworks/UserMode/Event">
<LifetimeId>{423c624a-94af-4419-a83a-102a25fc7b3d}</LifetimeId>
<Problem>8</Problem>
<DetectedBy>2</DetectedBy>
<ActiveOperation>0</ActiveOperation>
<ExitCode>1879048193</ExitCode>
<Message>0</Message>
<Status>4294967295</Status>
</UMDFHostProblem>
</UserData>
</Event>


Hardware:
Item Value
OS Name Microsoft Windows 10 Education
Version 10.0.19041 Build 19041
Other OS Description Not Available
OS Manufacturer Microsoft Corporation
System Name DESKTOP-QDSF452
System Manufacturer System manufacturer
System Model System Product Name
System Type x64-based PC
System SKU SKU
Processor AMD Ryzen 5 3600 6-Core Processor, 3593 Mhz, 6 Cores, 12 Logical Processors
BIOS Version/Date American Megatrends Inc. 2007, 12/31/2019
SMBIOS Version 3.1
Embedded Controller Version 255.255
BIOS Mode UEFI
BaseBoard Manufacturer ASUSTeK COMPUTER INC.
BaseBoard Product TUF B450-PRO GAMING
BaseBoard Version Rev X.0x
Platform Role Desktop
Secure Boot State Off
PCR7 Configuration Binding Not Possible
Windows Directory C:\WINDOWS
System Directory C:\WINDOWS\system32
Boot Device \Device\HarddiskVolume2
Locale United States
Hardware Abstraction Layer Version = "10.0.19041.421"
User Name HOME\administrator
Time Zone W. Europe Daylight Time
Installed Physical Memory RAM 64.0 GB
Total Physical Memory 63.9 GB
Available Physical Memory 50.4 GB
Total Virtual Memory 73.4 GB
Available Virtual Memory 59.9 GB
Page File Space 9.50 GB
Page File C:\pagefile.sys
Kernel DMA Protection Off
Virtualization-based security Running
Virtualization-based security Required Security Properties
Virtualization-based security Available Security Properties Base Virtualization Support, DMA Protection, UEFI Code Readonly, Mode Based Execution Control
Virtualization-based security Services Configured
Virtualization-based security Services Running
Device Encryption Support Reasons for failed automatic device encryption: TPM is not usable, PCR7 binding is not supported, Hardware Security Test Interface failed and device is not Modern Standby, Un-allowed DMA capable bus/devices detected, TPM is not usable
A hypervisor has been detected. Features required for Hyper-V will not be displayed.

:)



Issue with Windows 10 RDP

When a slight drop happens for users they don't get a reconnect message. It freezes up. This happens when users are using RDP from a Windows 10 machine into an RDS. We have never seen the issue with Windows 7. Please advise on how to fix as this seems
to be a bug.



Win 10 2004 update No AMD graphics

Before upgrading anything else to 2004, I would suggest checking out the current Known Issues list.

There are several -

https://docs.microsoft.com/en-us/win...indows-10-2004



RDS 2016 screen issue

Hello,

I don't know if this is the right place for my question because it's about server RDS 2016.

We have a RDS 2016 evironment en randomly some client have strange screen issue's, distorted screen in their RDS session. People with the problems are switching often between application and it looks like screen caching problem. When disconnecting the session
and reconnect the problem is solved. See screenshow below.





What have we done:

* Disabled persistent cache under advanced RDP settings clients.

* Disabled other settings under advanced RDP settings clients

* There is nog difference between connecting with thin client or fat client
