Windows 10: Windows partition status not showing

I remember I deleted a small windows partition and I think that is about ~200mb. And, my system was not booting, but I rebuild boot rec and system booted. From then on, the partition status isn't showing like regular, there's a blue status on each partitions, it's not visible now. Check the photo attached!

:)



Help! Data partition not showing under my computer

This is happening on a windows 2000 server. Our second partition of the system, for data is not showing under my computer. Here are the properties of it in disk management:





Now under logical drives its listed as F and shows free space available.

Suggestions on how to fix this?



W7 Hard drive partition issue

to get rid of that 100 meg windows partition that setup creates for you on a new install on a blank hdd:

- press shift+f10 when on the partition management screen in setup <-- this opens a command prompt
- diskpart <-- start the windows command line partition management tool
- list disk <--- list the installed hdds in this computer for the next step
- select disk 0 <- might have to replace 0 with the number of the correct disk
- clean <-- this will erase all data on the disk you selected one step up- dont use the wrong disk!
- create partition primary <- creates a primary partition taking up all space on the drive, adjust the command if necessary
- exit, exit to exit diskpart and the command prompt
- click refresh in partition manager and select your newly created partition and install to that



windows 7 (one partition dissapeared)

It sometimes happens. On my supervisor computer, a partition was made when he was using Windows XP with a third party software. With each fresh install, I have to assign a letter manually to that partition, else it don't show up in explorer even for Windows 7 RTM fresh install. I have seen it, that's why I have suggested the procedure.
