Windows 10: Deleted Partition on HDD - How do I restore it, and the data within?

In my efforts to fix my previous problem, I resorted to a fresh install of Windows 10. I have two drives - one is an SSD on which I installed only Windows-related files, and the other is a 500gb traditional hard drive on which everything else was installed. It was during the install of Windows, through the Windows Media Creation Tool method (created installation media onto USB, booted from that USB) that I got to the step where I was to format the disk(s) for a fresh install. Forgetting that both the SSD and HDD were both still installed, I'm 99% sure that I removed a partition on the HDD by mistake.


Now, the HDD shows up as a Disk Drive in Device Manager, but it doesn't show up in File Manager. It shows up as Disk 1 in Disk Management, but as 465gb of unallocated space and with no option to assign a drive letter - the only options in Disk Management are Convert to GPT, Convert to Dynamic Disk, and to create a New Simple Volume.


The only things I've done so far as scan the drive for lost partitions and recoverable data, but I haven't actually recovered any of the data or tried to recover the partitions yet. And since its not mounted or accessible I haven't overwritten anything (I think), and I haven't formatted or done any converting.


I'm able to see (probably) all the files on the HDD through freeware/trialware tools like Easeus, but I don't have enough space on my SSD to recover them all to. Ideally, I could restore the partition and just mount it back as a normal drive. Is that possible?


At the moment, I'm running a deep analysis with TestDisk but I'm a bit afraid to do anything more since I'm not 100% comfortable with cmd prompt stuff. TIA.

:)



How to recover files off a HDD from a deleted partition? help!!!

Thanks for your reply. I used my m8s program and it worked like a dream, recovered all the files and also deleted ones from yrs back, was amazed how well it did. Next step is i will use that Partition Table Doctor to recover the deleted partition. Thanks for the link *Toast :toast:



W7 Hard drive partition issue

to get rid of that 100 meg windows partition that setup creates for you on a new install on a blank hdd:

- press shift+f10 when on the partition management screen in setup <-- this opens a command prompt
- diskpart <-- start the windows command line partition management tool
- list disk <--- list the installed hdds in this computer for the next step
- select disk 0 <- might have to replace 0 with the number of the correct disk
- clean <-- this will erase all data on the disk you selected one step up- dont use the wrong disk!
- create partition primary <- creates a primary partition taking up all space on the drive, adjust the command if necessary
- exit, exit to exit diskpart and the command prompt
- click refresh in partition manager and select your newly created partition and install to that



Help! Data partition not showing under my computer

This is happening on a windows 2000 server. Our second partition of the system, for data is not showing under my computer. Here are the properties of it in disk management:





Now under logical drives its listed as F and shows free space available.

Suggestions on how to fix this?
