Windows 10: Deleted SSD partition on Windows Setup and now it won't show anywhere

As the title says, I have deleted the existing partition in an attempt to install a fresh copy of windows.

On my sistem I have a HDD and a SSD. Now the SSD won't show anywhere. Only the HDD.

I have checked Device Manager and Disk Management and it does not show. Even in BIOS the option which was before to boot from the SSD is now a blank selectable cell


Is there any way I can restore de SSD to be able to use it ?

:)



Deleted SSD partition

I was originally running Windows 10 on a Dell machine with a HDD and SSD in RAID 0 configuration. I have inadvertantly deleted the SSD partition when doing a Windows 10 re-install. Can anyone advise how to restore the RAID 0 setup and get the SSD partition
back? The SSD is visible in BIOS but not in Device Manager/Disk Management.



W7 Hard drive partition issue

to get rid of that 100 meg windows partition that setup creates for you on a new install on a blank hdd:

- press shift+f10 when on the partition management screen in setup <-- this opens a command prompt
- diskpart <-- start the windows command line partition management tool
- list disk <--- list the installed hdds in this computer for the next step
- select disk 0 <- might have to replace 0 with the number of the correct disk
- clean <-- this will erase all data on the disk you selected one step up- dont use the wrong disk!
- create partition primary <- creates a primary partition taking up all space on the drive, adjust the command if necessary
- exit, exit to exit diskpart and the command prompt
- click refresh in partition manager and select your newly created partition and install to that



Help! Data partition not showing under my computer

This is happening on a windows 2000 server. Our second partition of the system, for data is not showing under my computer. Here are the properties of it in disk management:





Now under logical drives its listed as F and shows free space available.

Suggestions on how to fix this?
