Windows 10: Disk Manager shows wiped (clean) drive to be partitioned with data.

Discus and support Disk Manager shows wiped (clean) drive to be partitioned with data. in Windows 10 Drivers and Hardware to solve the problem; Hi TenForums: I wiped a backup drive with Wipe Drive software. I connected my "working drive" to the system with the clean drive connected also. Disk... Discussion in 'Windows 10 Drivers and Hardware' started by w10enthusiastic, Jul 25, 2021.

  1. Disk Manager shows wiped (clean) drive to be partitioned with data.


    Hi TenForums: I wiped a backup drive with Wipe Drive software. I connected my "working drive" to the system with the clean drive connected also. Disk Manager showed the wiped (clean) drive to be partitioned with data. Do you have any comments? My Windows 10 Version: 21H1 Build: 19043.1110 Experience Pack: 120.2212.3530.0

    :)

    w10enthusiastic, Jul 25, 2021
    #1

  2. Help! Data partition not showing under my computer

    This is happening on a windows 2000 server. Our second partition of the system, for data is not showing under my computer. Here are the properties of it in disk management:


    Disk Manager shows wiped (clean) drive to be partitioned with data. partition.jpg


    Now under logical drives its listed as F and shows free space available.

    Suggestions on how to fix this?

    Hybrid_theory, Jul 25, 2021
    #2
  3. W1zzard Win User
    W7 Hard drive partition issue

    to get rid of that 100 meg windows partition that setup creates for you on a new install on a blank hdd:

    - press shift+f10 when on the partition management screen in setup <-- this opens a command prompt
    - diskpart <-- start the windows command line partition management tool
    - list disk <--- list the installed hdds in this computer for the next step
    - select disk 0 <- might have to replace 0 with the number of the correct disk
    - clean <-- this will erase all data on the disk you selected one step up- dont use the wrong disk!
    - create partition primary <- creates a primary partition taking up all space on the drive, adjust the command if necessary
    - exit, exit to exit diskpart and the command prompt
    - click refresh in partition manager and select your newly created partition and install to that

    W1zzard, Jul 25, 2021
    #3
  4. Disk Manager shows wiped (clean) drive to be partitioned with data.

    Disk Management

    Hi Keith,

    Thanks for providing the detail that was requested previously. Since the disk management screen that you saw is showing greyed out options, we suggest that you follow the steps below to change the partition type of your internal drive:

    • Open Disk Management then right click the partition on the disk you want to covert and select Delete Volume.
    • Once you complete the process you will see the whole disk shown as two separate unallocated spaces. Right-click the disk and select Convert to GPT disk.

    After the conversion, you will be able to use the whole disk and then you can create new separate partitions.

    We look forward to your response to our queries.

    Jordan Dom, Jul 25, 2021
    #4
