Windows 10: DISM - Create Bootable ISO with Multiple Windows 10 Images

How to: DISM - Create Bootable ISO with Multiple Windows 10 Images


Information Quite a many of us Windows geeks are in to customizing Windows install images. For instance, I like to do three different deployment / install images of the same Windows version and edition. One is "plain vanilla", default original Windows install media for a specific version and edition, another the same but containing all my preferred software pre-installed, and one more, multilingual Windows image with software pre-installed, allowing to select Windows language to be installed. I would then like these different Windows images and install options to be available in a single ISO file or bootable USB flash drive.

A post by a fellow member I saw today made me decide to write this tutorial:

No third party tools are required. Windows native DISM (Deployment Image Service and Management Tool) can do it. In fact, using DISM for this is quite fast and easy.

This tutorial will show how to put multiple Windows images to a single WIM file containing all your preferred Windows install images, and how to create an install media (ISO / USB) which, when booted from it, allows you to choose which of the Windows images will be installed.



Contents [/i] Click links to jump to any part

[table][tr][td]Part One:[/td] [td]Create Base WIM Image[/td] [/tr] [tr][td]Part Two:[/td] [td]Add other images to base WIM[/td] [/tr] [tr][td]Part Three:[/td] [td]Create ISO or USB Flash Drive[/td] [/tr] [/table]



Part One [/i] Create Base WIM Image
1.1) Create a folder on your PC, and copy contents of Windows 10 install media, either mounted ISO file or USB flash drive to it.

Name the folder as you want to. In this tutorial I use folder D:\ISO_Files, and copy contents of mounted ISO of Windows 10 x64 version 1903 / 19H1 to it.


Note If your goal is to create a multi-image WIM containing both 32-bit and 64-bit Windows images, the base image must be 32-bit. In this case, be sure to copy contents of 32-bit mounted ISO or USB media to ISO_Files folder.
1.2) Create another folder to save the multi-image WIM. In this tutorial, I will use folder D:\WIM for that.

1.3) Open an elevated Command Prompt, enter following command and check index value for your preferred edition, the edition you want to use a base in multi-image WIM:

dism /Get-WimInfo /WimFile:\ISO_Files\Sources\install.wim

Replace D:\ISO_Files with path to folder you created in Step 1.1. If your ISO_Files folder content was copied from media created with Windows Media Creation Tool, replace install.wim with install.esd.

In my case, I want to use PRO edition, noting its index value 6:




1.4) Enter following command to create base WIM:

Dism /Export-Image /SourceImageFile:\ISO_Files\Sources\install.wim /SourceIndex:6 /DestinationImageFile:\WIM\install.wim /DestinationName:"W10 PRO version 1903 x64 (original)"

Replace D:\ISO_Files with path to folder you created in Step 1.1, D:\WIM with path to folder you created in Step 1.2, and SourceIndex:6 value with actual index value to your base WIM edition. If your ISO_Files folder content was copied from media created with Windows Media Creation Tool, replace install.wim with install.esd in SourceImageFile.

I suggest using clear, descriptive name for both this base WIM, and additional WIM files added to this base. In multi-architecture WIM, it is also important to include bit version to name. In this example, I named my base WIM as W10 PRO version 1903 x64 (original)".


Part Two [/i] Add other images to Base WIM


Note In this example I will add two W10 PRO x64 Insider Build 18898 images to base. First one is heavily customized one but without any pre-installed software, and the second one also customized and with all my preferred pre-installed software.

How to create and capture custom Windows images, see this tutorial: Create Windows 10 ISO image from Existing Installation 2.1) I have saved my captured 18898 W10 x64 PRO EN-GB WIM files in folders G:\Captures\EN-GB\18898CustomNoSoftware and G:\Captures\EN-GB\18898CustomWithSoftware.

I will add the first one to base with same command than in Step 1.4, again using a descriptive name. Command to add the 18898 image with no software:

Dism /Export-Image /SourceImageFile:G:\Captures\EN-GB\18898CustomNoSoftware\install.wim /SourceIndex:1 /DestinationImageFile:\WIM\install.wim /DestinationName:"Build 18898 x64 PRO (no software)"

Notice that as the image is self made, it only contains one edition (PRO) with index value 1. Therefore, I did not have to check index values.

And then the one with pre-installed software:

Dism /Export-Image /SourceImageFile:G:\Captures\EN-GB\18898CustomWithSoftware\install.wim /SourceIndex:1 /DestinationImageFile:\WIM\install.wim /DestinationName:"Build 18898 x64 PRO (with software)"

2.2) In screenshot the command to create base WIM in Step 1.4 (#1), and commands to add two additional images to base in Step 2.1 (#2 & #3):





Part Three [/i] Create ISO or USB Flash Drive
3.1) In your ISO_Files\Sources folder (see step 1.1), delete original install.wim or install.esd file:




3.2) Copy the modified install.wim file from WIM folder (see step 1.2) to ISO_Files\Sources folder

3.3) To create an ISO file from contents in ISO_Files folder, see Part Five in this tutorial: Create Windows 10 ISO image from Existing Installation

3.4) The multi-image WIM file you created is usually bigger than 4 GB. Because of that, normal methods to create USB install media do not work, due FAT32 file size limit. In that case, see this tutorial for how to create a USB install media from your ISO_Files folder: Create bootable USB installer if install.wim is greater than 4GB
That's it! When you install Windows using install media you just created, you can choose what version and edition to install:




Kari

:)
