    Hyper-V Nested Virtualization: Run virtual machines on virtual machine


    How to: Hyper-V Nested Virtualization: Run virtual machines on virtual machine

    Hyper-V Nested Virtualization: Run virtual machines on virtual machine [​IMG]
    Information Nested Virtualization means that user can enable Hyper-V on existing virtual machines, and run virtual machines and Windows Sandbox on them.

    To make Nested Virtualization to work, it and MAC Address Spoofing or NAT networking must be enabled separately for each first level host VM. The script in this tutorial will use MAC Spoofing.

    Wikipedia:

    To be honest, this is a feature that only interests real virtualization enthusiasts. One practical use is to run emulators or other software that requires regular restarts on a second level nested VM on first level VM, to avoid restarting host.

    I use Nested Virtualization to save current state of Hyper-V Production Checkpoints.

    If you want to enable Hyper-V on your Hyper-V virtual machines, this tutorial shows how to do it with a simple PowerShell script.

    Enable Nested Virtualizationt1) The script to enable Nested Virtualization:

    Code:
    You can download the script from my OneDrive:

    Download

    As always with downloaded content, be sure to unblock downloaded file before using it!

    2) Check that running local scripts in PowerShell is enabled (tutorial):

    Hyper-V Nested Virtualization: Run virtual machines on virtual machine [​IMG]


    3) Be sure the virtual machine on which you want to allow nested virtualization is turned off. Run the script by right clicking it and selecting Run with PowerShell:

    Hyper-V Nested Virtualization: Run virtual machines on virtual machine [​IMG]


    Alternatively, if using PowerShell ISE, open the script from File menu and press F5 to run it:

    Hyper-V Nested Virtualization: Run virtual machines on virtual machine [​IMG]


    4) If PowerShell warns you about Execution Policy change, press Y to accept it:

    Hyper-V Nested Virtualization: Run virtual machines on virtual machine [​IMG]


    5) Running the script, it will auto elevate (switch to admin mode if started in normal user mode), and lists all current Hyper-V virtual machines on your host:

    Hyper-V Nested Virtualization: Run virtual machines on virtual machine [​IMG]


    6) Type or Copy & Paste the name of the virtual machine on which you want to enable nested virtualization, press Enter.

    Hyper-V Nested Virtualization: Run virtual machines on virtual machine [​IMG]
    Tip In PowerShell (and in Command Prompt), you cannot copy using context menu (mouse right click, select Copy). Also, by default Copy & Paste with keyboard shortcuts is disabled, although it can be enabled in PowerShell (and Command Prompt) Properties in Options tab.

    Instead, mark the string you want to copy with mouse, in this case name of a VM. To mark a string, press and hold down mouse left button on top of first character, and move to end of the string you want to copy. Release the mouse button, press Enter to copy.

    Pasting is done with right mouse button.

    Hyper-V Nested Virtualization: Run virtual machines on virtual machine [​IMG]


    7) That's it. Nested virtualization on selected VM is now enabled:

    Hyper-V Nested Virtualization: Run virtual machines on virtual machine [​IMG]


    8) Start the VM, setup Hyper-V on it (tutorial). In screenshot I am running Windows 7 on a Hyper-V VM on Windows 10 Hyper-V VM running on my host computer:

    Hyper-V Nested Virtualization: Run virtual machines on virtual machine [​IMG]

    Happy virtualization, geeks!

    Kari

    :)

    Brink, Jul 17, 2018
